DMX512 Master controller is the output signal of international standard DMX512/1990. It not only can control all the LED lights that receiving the standard DMX signal in the market, but also can work with our DMX decoder to control the general LED lights without DMX512.

DMX512 Master controller
  • MS Panel MS-WF-512
    Model: MS-WF-512
    Input voltage: 5-24Vdc
    Wireless type: WiFi, RF 2.4GHz
    Output signal: DMX512, L-BUS
    Working temp.: - 20°C~55°C
    Product size: L146×W106×H18(mm)
    Packing size: L219×W196×H50(mm)
    Weight(N.W.): 230g

  • USB-DMX controller LTSA512(Off-line Pattern)
    Input Voltage 5V DC
    Power Consumption <2W
    Connection Mini USB
    Internal Memory 4000 steps
    Channel 512
    Output Connector XLR-3 green terminal
    Transmission Signal DMX512
    PC Software LED player
    Working Temperature -30℃~65℃
    Package Size L140×W200×H52(mm)
    Weight(G.W.) 350g
  • USB-DMX controller LTSA1024(Off-line Pattern)
    Input Voltage 5V DC
    Power Consumption <2W
    Connection Mini USB
    Internal Memory 4000 steps with 512 channels, 100 000 steps with 16 channels
    Channel 1024
    Output Connector XLR-3 green terminal
    Transmission Signal DMX512
    PC Software LED player
    Working Temperature -25℃~70℃
    Package Size L140×W200×H52(mm)
    Weight(G.W.) 350g

  • RDM WiFi Controller WiFi-RDM01
    Model: WiFi-RDM01
    Protocol: 2.4GHz Wi-Fi, 802.11b/g/n,ANSI E1.20-2010 RDM
    Input voltage: 5-24Vdc
    Output: DMX512/RDM
    Working temperature: -30℃~55℃
    Dimensions: L125×W33×H20mm
    Package size: L127×W35×H24mm
    Weight (G.W.): 110g
  • Color temperature Touch Panel Controller UX2
    Input voltage 5V DC 1A
    Output signal RF2.4G+DMX512
    Control mode Color temperature
    Working temperature -30℃~55℃
    Package Size L132×W180×H35mm
    Weight (N.W.) 370g
  • LED Lighting Control System LT-600(Off-line Pattern)
    Working voltage DC12V
    Output signal channels 16 Channels
    Loading capability per channel 512-1920 pixels/channel
    Off-line storage media SD memory card
    SD card capability 2GB Max.
    Grey level Max. 65536 scale
    Refreshing frequency 60Hz~3000Hz
  • USB-DMX controller LT512(Off-line Pattern)
    Input Voltage 5V DC
    Power Consumption <2W
    Connection Mini USB
    Internal Memory 120 steps
    Channel 512
    Output Connector XLR-3
    Transmission Signal DMX512
    PC Software LED player
    Working Temperature -30℃~65℃
    Package Size L140×W200×H52(mm)
    Weight(G.W.) 330g
  • EX61 Dimming Knob Panel
    Input voltage 100~240Vac
    Output signal RF 2.4GHz, DMX512
    Working temperature -10℃~55℃
    Dimensions L86×W86×H50(mm)
    Package Size L106×W106×H60(mm)
    Weight(G.W.) 235g

  • EX1 Dimming European-style touch panel
    Input voltage 100~240V AC
    Output signal RF 2.4G+DMX512
    Control mode sync control
    Wireless distance 30m
    Working temperature -30℃~55℃
    Dimension L86×W86×H36mm
    Package Size L113×W112×H50mm
    Weight (G.W) 225g
  • EX1S Dimming European-style touch panel
    Input voltage 100~240V AC
    Output signal RF 2.4G+DMX512
    Control mode sync control
    Wireless distance 30m
    Working temperature -30℃~55℃
    Dimension L86×W86×H36mm
    Package Size L113×W112×H50mm
    Weight (G.W) 225g
  • EX2 CT European-style touch panel
    Input voltage 100~240V AC
    Output signal RF 2.4G+DMX512
    Control mode sync control
    Wireless distance 30m
    Working temperature -30℃~55℃
    Dimension L86×W86×H36mm
    Package Size L113×W112×H50mm
    Weight (G.W) 225g
  • EX3 RGB European-style touch panel
    Input voltage 100~240V AC
    Output signal RF 2.4G+DMX512
    Control mode sync control
    Wireless distance 30m
    Working temperature -30℃~55℃
    Dimension L86×W86×H36mm
    Package Size L113×W112×H50mm
    Weight (G.W) 225g
  • EX3S - Touch Panel (RGB)
    Input voltage 100-240Vac
    Output signal RF 2.4GHz, DMX512
    Control mode Synchronous control
    Working temperature -30℃~55℃
    Dimensions L86×W86×H36(mm)
    Package Size L113×W112×H50(mm)
    Weight(G.W.) 225g
  • EX4 RGBW European-style touch panel
    Input voltage 100~240V AC
    Output signal RF 2.4G+DMX512
    Control mode sync control
    Wireless distance 30m
    Working temperature -30℃~55℃
    Dimension L86×W86×H36mm
    Package Size L113×W112×H50mm
    Weight (G.W) 225g
  • EX4S RGBW Touch Panel
    Input voltage 100-240Vac
    Output signal RF 2.4GHz, DMX512
    Control mode Synchronous control
    Working temperature -30℃~55℃
    Dimensions L86×W86×H36(mm)
    Package Size L113×W112×H50(mm)
    Weight(G.W.) 225g
  • EX5 Dimming European-style touch panel
    Input voltage 100~240V AC
    Output signal RF 2.4G+DMX512
    Control mode 4 zones control
    Wireless distance 30m
    Working temperature -30℃~55℃
    Dimension L86×W86×H36mm
    Package Size L113×W112×H50mm
    Weight (G.W) 225g
  • EX6 CT European-style touch panel
    Input voltage 100~240V AC
    Output signal RF 2.4G+DMX512
    Control mode 4 zones control
    Wireless distance 30m
    Working temperature -30℃~55℃
    Dimension L86×W86×H36mm
    Package Size L113×W112×H50mm
    Weight (G.W) 225g
  • EX7 RGB European-style touch panel
    Input voltage 100~240V AC
    Output signal RF 2.4G+DMX512
    Control mode 4 zones control
    Wireless distance 30m
    Working temperature -30℃~55℃
    Dimension L86×W86×H36mm
    Package Size L113×W112×H50mm
    Weight (G.W) 225g
  • EX8 RGBW European-style touch panel
    Input voltage 100~240V AC
    Output signal RF 2.4G+DMX512
    Control mode 4 zones control
    Wireless distance 30m
    Working temperature -30℃~55℃
    Dimension L86×W86×H36mm
    Package Size L113×W112×H50mm
    Weight (G.W) 225g
  • EX8S RGBW Touch Panel (4 zones)
    Input voltage 100-240Vac
    Output signal RF 2.4GHz, DMX512
    Control mode Synchronous control
    Working temperature -30℃~55℃
    Dimensions L86×W86×H36(mm)
    Package Size L113×W112×H50(mm)
    Weight(G.W.) 225g
  • LED WiFi Controller WiFi-101-DMX4
    Communication standard 2.4G Wi-Fi,802.11b/g/n protocol
    Input voltage 12-24Vdc
    Output DMX512 512CH
    Working temperature -30℃~55℃
    Dimensions L125×W33×H20(mm)
    Package Size L127×W35×H24(mm)
    Weight (N.W.) 70g

  • Dimming Touch Panel Controller UX5
    Input voltage 5V DC 1A
    Output signal RF2.4G+DMX512
    Control mode DIM,4 Zones control
    Working temperature -30℃~55℃
    Package Size L132×W180×H35mm
    Weight (N.W.) 370g
  • Color temperature Touch Panel Controller UX6
    Input voltage 5V DC 1A
    Output signal RF2.4G+DMX512
    Control mode CT,4 Zones control
    Working temperature -30℃~55℃
    Package Size L132×W180×H35mm
    Weight (N.W.) 370g
  • RGBW Touch Panel Controller UX8
    Input voltage 5V DC 1A
    Output signal RF2.4G+DMX512
    Control mode RGBW, 4 Zones control
    Working temperature -30℃~55℃
    Package Size L132×W180×H35mm
    Weight (N.W.) 370g
  • DX Series Touch Panel Controller DX5
    Input voltage AC100~240V
    Output signal RF 2.4G+DMX512
    Control mode 4 Zones control
    Working temperature -20℃~60℃
    Dimensions L86×W86×H36mm
    Package Size L112×W112×H48mm
    Weight (N.W.) 225g
  • DX Series Touch Panel Controller DX6
    Input voltage AC100~240V
    Output signal RF 2.4G+DMX512
    Control mode 4 Zones control
    Working temperature -20℃~60℃
    Dimensions L86×W86×H36mm
    Package Size L112×W112×H48mm
    Weight (N.W.) 225g
  • DX series touch panel controller DX8
    Input voltage AC100~240V
    Output signal RF 2.4G+DMX512
    Control mode 4 Zones control
    Working temperature -20℃~60℃
    Dimensions L86×W86×H36mm
    Package Size L112×W112×H48mm
    Weight (N.W.) 225g
  • DMX Controller LT-800
    Working Voltage DC12 (with an adapter to convert
    Power Consumption <2W
    Output Signal DMX512
    Output Loop 1 Port
    Transmission Speed 250Kbps
    Change mode 580 modes
    Control Quantity

    512 DMX channels( 170 pixels)

    Dimming range 0~100%
    Working Temperature -30℃~65℃
    Product Dimensions L163×W108×H40mm
    Package Dimensions L260×W132×H46mm
    Weight(G.W) 760g
