Product features:

1. Adopt DALl standard protocol lEC62386-102,207.209. 2. Support switch, dimming and color adjustment function; zone control is available. 3. DALl bus supply power. 4. Easy to set addresses. 5. Support scene, group, unicast and broadcast mode. 6. Touch vibration.

DALI Panel

E6D

Output Signal	DALI
Bus Power Current	200mA@16V
Rated Parameters	100-240V~，50/60Hz
Control Type	DIM, CT, RGB, RGBW, RGBCW
Wireless Type	Bluetooth 5.0 SIG Mesh
Compatible remote	B1、B2、B5、B8、RC4-BLE
Compatible APP	L-Home、 NFC Lighting
Working Temperature	-25°C~50°C
Dimensions	86x86x52mm(LxWxH)
Package Size	102x102x73mm(LxWxH)
Weight	130g

Download Manual

EDT4

Output signal	DALI
Power Supply	DALI power
Dimming key	RGBW control
Power consumption	< 6mA@16V
working temperature	-30 ~55 ℃
Dimension	L86×W86×H37(mm)
Package Size	L113×W112×H50(mm)
Weight (G.W)	240g

Download Manual

EDT3

Output signal	DALI
Power Supply	DALI power
Dimming key	RGB control
Power consumption	< 6mA@16V
working temperature	-30 ~55 ℃
Dimension	L86×W86×H37(mm)
Package Size	L113×W112×H50(mm)
Weight (G.W)	240g

Download Manual

EDT2

Output signal	DALI
Power Supply	DALI power
Dimming key	CT control
Power consumption	< 6mA@16V
working temperature	-30 ~55 ℃
Dimension	L86×W86×H37(mm)
Package Size	L113×W112×H50(mm)
Weight (G.W)	240g

Download Manual

EDT1

Output signal	DALI
Power Supply	DALI power
Dimming key	Dimming control
Power consumption	< 6mA@16V
working temperature	-30 ~55 ℃
Dimension	L86×W86×H37(mm)
Package Size	L113×W112×H50(mm)
Weight (G.W)	240g

Download Manual

E6-DA1

Power supply	DALI power
Output signal	DALI
Dimming style	Spin
Static current	6mA@16V
Standby current	4mA@16V
Working temperature	-10℃~55℃
Dimensions	L86×W86×H50(mm)
Package Size	L106×W106×H60(mm)
Weight(G.W.)	235g

Download Manual

EDA1

Output signal	DALI
Power Supply	DALI power
Dimming key	1CH control
Static current	6mA@16V
Standby current	4mA@16V
working temperature	-30 ~55 ℃
Dimension	L86×W86×H36(mm)
Package Size	L113×W112×H50(mm)
Weight (G.W)	200g

Download Manual

EDA2 (2 zones)

Output signal	DALI
Power Supply	DALI power
Dimming key	2CH control
Static current	6mA@16V
Standby current	4mA@16V
working temperature	-30 ~55 ℃
Dimension	L86×W86×H36(mm)
Package Size	L113×W112×H50(mm)
Weight (G.W)	200g

Download Manual

EDA3 (3 zones)

Output signal	DALI
Power Supply	DALI power
Dimming key	3CH control
Static current	6mA@16V
Standby current	4mA@16V
working temperature	-30 ~55 ℃
Dimension	L86×W86×H36(mm)
Package Size	L113×W112×H50(mm)
Weight (G.W)	200g

Download Manual

EDA4 (4 zones)

Output signal	DALI
Power Supply	DALI power
Dimming key	4CH control
Static current	6mA@16V
Standby current	4mA@16V
working temperature	-30 ~55 ℃
Dimension	L86×W86×H36(mm)
Package Size	L113×W112×H50(mm)
Weight (G.W)	200g

Download Manual
